Metal Diaphragm Valves

Depending on design, these valves are specifically suitable for highly-pure to heavily contaminated liquid and gaseous, inert and corrosive media.

Just as classical control valves, diaphragm valves also have good control properties, especially for media which are contaminated or contain particles.

The major areas of use are processes in a vast range of different industrial applications.

Get in touch

Specifications



Operating Pressure

0 – 10 bar

Operating Temperature

10 – 180°C

Nominal Size

DN 4 – 300

Body Materials

Cast iron, S.G. iron, cast steel, brass, stainless steel (investment casting, forged bodies, block material). Lined with hard and soft rubber, PP, PFA, PVDF, glass, halar etc

Seal Materials

CSM (Hypalon), NBR (Perbunan), FPM (fluorine rubber), IIR (butyl), CR (neoprene), EPDM, EPDM/PTFE (laminated and loose, concave and convex)

Connection Types

Butt-weld spigots, clamps and union ends, threaded sockets, threaded spigots, flanges. Connection Types are generally available with different standards and norms (DIN, ANSI, BS, JIS etc.)

Operation

Manually operated, pneumatically or hydraulically operated or motorised

Body Configuration

2/2 way body (2/2 way valve), T valve (3/2 way valve), tank valve (B600), multi-port valve (M600)

Surfaces

Surface finishes for stainless steel bodies down to 0.25 μm Ra and electropolished are available
